Thursday, January 09, 2014

So You Want To Be A CISSP?

This post is for those who've been doing some network security and want to make it official and get the CISSP certification.

ISC2 has a set of intro videos to get you started. They are about 15 minutes each. The first is an introduction and then there is one for each of the 10 domains. This is not a course on becoming a CISSP, just an introduction to the type of information you would need to be familiar with.

If you are at that point of your career that moving firmly into the domain of security is appealing to you, this is a nice little preview of what's ahead of you.

Tuesday, November 05, 2013

Sophos UTM (with 10 licenses for Endpoint Protection) Free For Home Use

Sophos previously didn't have a full featured home-use antivirus.
They had one that you could run manually if you think you have an infection, and they had a home-use clause for their business customers that let them give it to employees for use at home for free, managed by the IT folks in the office, but there wasn't a way to buy it for home unless you wanted to buy the minimum size of 5 licenses for small business use.

Recently they made their UTM product (the firewall formerly known as Astaro Linux) available for free to home users and it comes with 10 licenses for home use for the full featured Endpoint Protection client.

The central configuration console on the UTM is not as slick as the Enterprise console, and it doesn't allow you to control Sophos' hard drive encryption software, but it does let you set up the Antivirus, Web Filtering, Firewall, and Intrusion Protection features. It doesn't need a Windows domain, so you can use it on Windows Home editions. The one thing that makes it really only for techie home users is that the UTM has to be installed on dedicated hardware or in a Virtual Machine.

If you already know how to set up a VM, then you are ready to go, just download the pre-built VM, or the software ISO and give it a try.

So with this you get a full featured Endpoint Protection program and a network based firewall system with more different VPN options than I have ever seen in one product. This is great for people running home labs for networking courses or Infosec research.

Having played around with it a bit at home I would rank it's UTM firewall capabilities fairly low in terms of flexibility compared to the FortiGate UTMs I'm familiar with, but you can't beat free for home networks.

Thursday, September 19, 2013

Is It a VM?

Having a hard time keeping track of which machines on your network are virtual?

I have just the script for you. I wanted to have a way to quickly find out what machines were virtual at work, so I whipped this up in PowerShell today.

    [string]$ComputerName = 'localhost',

if ($ComputersListFile) {$computers = Get-Content -Path $ComputersListFile} else {$computers = $ComputerName}
if ($ComputerName -eq'localhost')
        if((Get-WmiObject -Class win32_bios).SerialNumber.StartsWith("VMware")) {Write-Output "This machine is a VM!"} else {Write-Output "This machine is probably not a VM"}
        invoke-command -ComputerName $computers -ScriptBlock {$hostname = hostname; if((Get-WmiObject -Class win32_bios).SerialNumber.StartsWith("VMware")) {Write-Output "$hostname is a VM!"} else {Write-Output "$hostname probably is not a VM"}}

This only works as it is for VMWare virtualization, not for Hyper-V or VirtualBox, but it would be easy to add tests for those too. The test is to look at the BIOS SerialNumber and see if it starts with the string "VMware". It's just that simple. ...You could also look at the MAC address of the NIC and see if the first few digits match one of the VMWare prefixes, but the BIOS string was easier.

Run it like this:

.\IsItAVM.ps1 -ComputerName computer1, computer2, computer3

or like this if you have a list of computers already in a file:

.\IsItAVM.ps1 -ComputersListFile U:\computers.txt

Of course, this will only work if the computer you are testing is Windows with PowerShell and has PowerShell remoting enabled, and you are not blocked by a firewall... but in an IT environment where PowerShell is being used for management this fits nicely.

Have fun!

Edit: Added a little bit of code to better handle the localhost case. If you just run it as .\IsItAVM.ps1 or manually specify just localhost in the -ComputerName then it will not try to use Invoke-Command, so it will not need remoting turned on for a localhost check. Also it gives a slightly different message on a localhost check.

Wednesday, September 11, 2013

Why You Want Your Next File Server To Be Win2012 - Dedup

In the teaser post I showed you this image. It is a little bit misleading. My 722GB of data actually occupies 483.72 GB of disk space.
To compress it down to less than 2gb would require a type of black magick even Microsoft isn't able to produce.

I am using Windows 2012 data deduplication, which is a new technology that saves disk space by looking at each block on the disk and if there are multiple blocks that are the same it only saves one copy. So, if you have several copies of the same file, even if they are a little bit different from each other, or if you have files with lots of repetition (like log files), it can save you lots of space.

Because I'm using Windows data deduplication, the size on disk only shows the size of the metadata. With PowerShell's Measure-DedupFileMetadata command I can get the actual space used.

Adding the SavedSpace shown with Get-DedupStatus to the DedupSize shown by Measure-DedupFileMetadata indeed does add up to 721.26... just short of the Size of 722.68GB reported by the Measure-DedupFileMetadata and 722GB reported by the GUI. Given a margin of error on that calculation to account for rounding, that seems right to me.

Ok, so it didn't shrink it down to 2GB like the teaser might have lead you to think, but shrinking 722GB down to 484 GB is pretty impressive still, that's about a 33% savings. With a volume size as large as this (yup that says 20TB, but it's not real, we'll get to that in a later post) NTFS can no longer do file compression (NTFS file compression is not possible on drives that have a larger cluster size than 4K), but the new data deduplication applied at the volume level makes decently efficient use of space.

By now you are probably starting to see why it's suddenly important to start learning about PowerShell, if you haven't already started. The Windows GUI will no longer be sufficient to properly administer newer versions of Windows. For the past several years it was necessary for Exchange Server admins to get the most out of that product, and for Server Core editions of Windows Server to be manageable at their own console, but now newer features like Disk Deduplication and Storage Pools, require it in order to get the most out of these features. Much like Linux and Cisco, Windows is headed to an age where those who understand it's command line will be able to do much more, and do it much more efficiently, than those who only learn it's graphical interface.

So how do you go about setting up deduplication?

For starters, you need a separate disk from your OS boot disk. (you can't dedup c:)

You can install it via the old fashioned GUI:
Go into Server Manager
Click "Manage"
Click "Add Roles and Features"
Work your way down to "Server Roles"
Under "File and Storage Services", enable "Data Deduplication"

or, just open PowerShell and type:
"Import-Module ServerManager"
"Add-WindowsFeature -name FS-Data-Deduplication"

Enable it on a volume via the GUI:

In the Server Manager, select "File and Storage Services", and then "Volumes".
Right click on a volume, and select "Configure Data Deduplication"

or, via PowerShell:
"Enable-DedupVolume M:"

In the next post I will get into the details of Storage Pools. This is a really neat feature of Windows 8 and 2012 that puts the old RAID system to shame.

Tuesday, September 10, 2013

Why You Want Your Next File Server To Be Win2012 - Teaser


There are going to be a few changes around here.

I realized that try as I might, I have not been sticking to the "Practical Tech Tips and Reviews for Everyday Users" in my tag line. In fact I don't think in the 8 years this blog has been going, I have ever written a review.

That tag line has limited what I feel is appropriate to post to this blog, which has meant that some things I might like to post never get posted for fear of scaring away the "Everyday Users" ...but then what I do post is often too technical for that demographic anyway. This week marks a change in the focus of this blog. From now on, I'm just dropping the tag line all together.  I will make no assumptions about who my audience is, and will post things strictly according to what I think is interesting enough, or important enough to share.

I will still try not to just repeat what you can find elsewhere on the internet. Inevitably I will talk about subjects that are being talked about somewhere else, but weighing in heavily with my own views, opinions and experiences. Some times things might get more technical around here than you are used to seeing here, but other times I might just share fun stuff I've found.

I hope that most of my readers will stay, but I am not writing this strictly to entertain one group of people, but because I have some things I'd like to share, and I will share with whomever is still listening.

Visible changes in the immediate future will be limited to just the logo at the top of the screen will lose that tagline. Over time though, I expect the blog content on average will get more technical, but not overwhelmingly so for anyone who already considers themselves a techie or advanced user.

Friday, September 06, 2013


It's been a while since I last posted something truly a tech tip for everyday users.
This is not something ground breaking and way out in the realm of the really techie user. Every user who is even moderately techie ought to already know about this, but for the enthusiast home user or future IT pro who hasn't yet run across Sysinternals (formerly WinInternals) you are really missing out.

Sysinternals has long provided really useful free utility programs for Windows that run with a small footprint and don't leave a lot of mess behind them after they run. You don't normally have to "install" them, just run them.

BgInfo is a neat little tool that will post some useful details about your computer in the corner of the screen so that you have a quick reference for which version of Windows you are using, What CPU your computer has, how much memory, and other details a tech support agent might ask about.

Desktops allows you to organize your applications on up to four virtual desktops so you can quickly switch between groups of applications. Put your Excel spreadsheet and bank stuff on one virtual screen, and facebook and twitter on another...

If you are making presentations often, or have a visual impairment, ZoomIt is a screen zoom and annotation tool designed for technical presentations, but generally useful for anyoone who wants to zoom in on stuff once in a while.

If you have ever run defrag and wondered how to defragment those system files that defrag can't touch, well Contig is there for that purpose.

For the advanced users, some of these tools are particularly useful in troubleshooting problems or investigating security issues. For example, if you needed to know what process is making outgoing connections to a certain IP that you suspect is related to malware, TCPView might help you track down just what program on your computer is doing that. Process Monitor (which is a replacement for two legacy Sysinternals utilities, Filemon and Regmon) can help you track a program's every move.

Some of the tools, like the PS tools and AD tools will only be of interest to pros working in an office environment.

Here is a quick free video course for those interested in some of sysinternals' more advanced tools. (you need a Windows Live/Hotmail login to get there, but that's free too).

Saturday, August 17, 2013

Finding The Culprit Of High Bandwidth Use

On Wednesday I was visiting my parents and Dad mentioned that over the last 2 months he'd been seeing some high bandwidth use on his home DSL. Typically in the past they'd never used more than 10-15GB/month because they don't use streaming video and the biggest bandwidth hog is probably uploading photos to Facebook. Lately it has had occasional days where the use has gone up to 5-7 GB in a day.

He had it narrowed down to one laptop because one of those days happened when they were not even home, but that laptop was still on.

Dad is a pretty techie guy, he worked for Honeywell computers out of college and then Bell Canada for a very long career specializing in large business PBX and 911 systems. He's never been afraid of computers. I think he'd rank highly on the MIT hacker test because he actually has programmed with punch cards.

Anyway, given that background this is what I've suggested to him:

Download and install Wireshark from
Once it is installed, open a CMD DOS prompt and change directory to C:\Program Files\Wireshark>

Run this command, and leave it running all day. It will record what servers on the internet (by IP addresses) you connected to and how much traffic was sent. This command also tells it to ignore traffic that is between two addresses that both start with 192.168...  thus ignoring anything that is local to your house.

tshark.exe -i Wi-Fi -z conv,ip,ip dst net 192.168 and src net not 192.168 or ip dst net not 192.168 and src net 192.168 > C:\users\public\tshark.txt

Note: you may need to change the "-i Wi-Fi" part to "-i Local Area Connection*" or something else.
Use "tshark -D" to find the list of network interfaces on your computer.

It should print "Capturing on 'Wi-Fi'" then a counter. Meanwhile in the file C:\users\public\tshark.txt it is recording what servers you connect to, if you use CTRL-C to stop it, or just close the CMD window, it will end the file with a chart of what connections it saw and how many bytes were transferred.

example output:
  3.708876 ->  TCP 74 [TCP Dup ACK 2393#21] 16378 > http [ACK] Seq=1 Ack=2076733 Win=1327 Len=0 SLE=2095609 SRE=2111581 SLE=2078185 SRE=2094157
  3.709305 ->  TCP 74 [TCP Dup ACK 2393#22] 16378 > http [ACK] Seq=1 Ack=2076733 Win=1327 Len=0 SLE=2095609 SRE=2113033 SLE=2078185 SRE=2094157
  3.710766 ->  TCP 54 16312 > http [ACK] Seq=1 Ack=1854205 Win=969 Len=0
  3.712005 ->  TCP 54 16312 > http [ACK] Seq=1 Ack=1857109 Win=964 Len=0
  3.712776 ->  TCP 74 [TCP Dup ACK 2393#23] 16378 > http [ACK] Seq=1 Ack=2076733 Win=1327 Len=0 SLE=2095609 SRE=2114485 SLE=2078185 SRE=2094157
IPv4 Conversations
                                               |       <- -="" nbsp="">      | |     Total     |    Relative    |   Duration   |
                                               | Frames  Bytes | | Frames  Bytes | | Frames  Bytes |      Start     |              |        <->                0         0    2419    138406    2419    138406     0.000000000         3.7128

Edit: Included a screen capture because Blogger doesn't seem to have any fixed-width fonts.
